Our MMO Ribbon Anode and Titanium Conductor Bar system represents a breakthrough in cathodic protection technology. This integrated solution combines the superior current-carrying capacity of titanium conductor bars with the exceptional electrochemical performance of Mixed Metal Oxide ribbon anodes, creating a complete protection system for structures.
Primary Applications:
Bridge Decks & Parking Garages: Superior corrosion protection for horizontal surfaces
Marine Structures: Piers, wharves, and sea walls exposed to saltwater
Building Foundations: Protection against soil-side corrosion
Industrial Facilities: Chemical plants and processing facilities with aggressive environments
System Advantages & Integrated Benefits
Uniform Current Distribution
Ribbon anode geometry ensures even current emission along the entire length, eliminating protection gaps and hot spots.
Easy Installation & Placement
Flexible ribbon design allows simple placement within concrete pours or surface mounting on existing structures.
Superior Mechanical Strength
Titanium conductor bars provide robust structural support and excellent current-carrying capacity.
Long-Term Reliability
Integrated system design ensures consistent performance throughout the structure's service life.
Minimal Maintenance
Once installed, the system operates maintenance-free with no moving parts or regular adjustments required.
Technical Specifications
MMO Ribbon Anode Specifications:
Parameter | Specification |
Base Material | Titanium Substrate (ASTM B265 Grade 1) |
Active Coating | Mixed Metal Oxide (Iridium/Tantalum) |
Ribbon Dimensions | 6.35mm width × 0.635mm thickness |
Standard Length | 152m/roll (custom lengths available) |
Current Capacity | 17mA/m in soil and 42mA/m in fine sand |
Titanium Conductor Bar Specifications:
Parameter | Specification |
Material | Commercial Pure Titanium (Grade 1) |
Standard Sizes | 12.7mm width × 0.9mm thickness |
Length Options | 100m/roll (custom available) |
Quality Verification & Testing
Accelerated Life Testing (NACE TM0108-2008)
Test Solution: 1 mol/L Sodium Sulfate (Na₂SO₄)
Current Density: 15,000 A/m²
Verified Service Life: > 72 hours
Performance Standard: Consistent coating integrity maintained throughout testing
Quality Assurance:
ISO 9001:2015 Certified Manufacturing
Batch Testing and Traceability
Third-Party Verification Available
Material Certifications Provided
System Configuration Options
Standard Ribbon Systems:
Single-ribbon configurations for basic protection
Multi-ribbon arrays for high-current requirements
Zone-based systems for large structures
Performance Comparison
Feature | MMO Ribbon System | Conventional Anodes |
Current Distribution | Excellent | Poor to Fair |
Installation Flexibility | Superior | Limited |
Service Life | 20+ Years | 5-10 Years |
Maintenance Requirements | None | Regular |
System Integration | Complete | Partial |
Lifetime Cost | Lowest | Higher |
Frequently Asked Questions
Q: What is the maximum spacing between ribbon anodes in concrete?
A: Typical spacing ranges from 0.8 to 1.2 meters, depending on concrete resistivity and protection requirements.
Q: Can the system be installed in existing structures?
A: Yes, surface-mounted and groove-installed options are available for retrofit applications.
Q: How are conductor bars connected to the ribbon anodes?
A: We recommend specialized welding techniques or mechanical clamps, with detailed procedures provided.
Q: What monitoring systems are compatible with your ribbon anodes?
A: The system works with all standard CP monitoring equipment, and we can provide integrated monitoring solutions.
Global Applications
Our MMO Ribbon Anode and Titanium Conductor Bar systems protect critical infrastructure worldwide, from highway bridges in North America to offshore platforms in the Middle East and port facilities in Asia.
